Power-Saving Screen
(When no signal is received for about 1 hr. the
screen switches to the power-saving mode)
When you push either of the MODE
button or the START/STOP button
or you ride the bicycle, the display
comes back to the measurement
display.
ST/STOP
MODE
SET
SET
Speed
0.0 (4.0) - 300 km/h
[0.0 (3.0) - 185 mph]
or
Cadence
0.0 (20.0) - 299.9 rpm
You can program the tire size.
Return to the Elapsed Time
Range of set: 10 - 2999 mm
Increase
the number
Decrease
the number
Display for Measurements
Mode Selection Illustrations (bottom of the screen)
Cdc
Cadence
0(20) - 299 rpm
or
Speed
0.0 (4.0) - 300.0 km/h
Av
Average Speed
0.0 - 300 km/h
[0.0 - 185.0 mph]
Odo
Odometer
0.0 - 99999 km [mile]
Mx
Maximum speed
0.0 (4.0) - 300.0 km/h
[0.0 (3.0) - 180.5 mph]
Dst
Trip Distance
0.00 - 999.99 km[mile]
Tm
Elapsed Time
0:00’00” - 9:59’59”
Return to Clock display
When the measurements
are stopped.
When the measurements
are stopped
Clock
0:00 - 23:59
[1:00 - 12:59]
While any measurement is
displayed on the screen
Return to Elapsed
Time display
For 2 sec.
MODE
MODE
ST/STOP
MODE
MODE
Increase the number
SET
SET
Set the hour
Set the minute
Setting The Clock Time
24 hour or 12 hour system is to be used with km/h or mph
unit respectively.
Auto-mode Icon
When lit, the measurements
starts or stops
automatically.
Cateye Astrale Cc Cd100 User Manual Download
Tm
Dst
Av
Cateye Astrale 8
SET
ST/STOP
MODE
ST/STOP
Specifications
Battery/Its Life : ----------------------------- A Lithium Battery (CR2032), Approx:3 yrs.
(Approx:1 hr per day usage.)
Control System : ---------------------------- 4-bit 1-chip micro-computer (with a crystal oscillator)
Display : -------------------------------------- Liquid crystal display
Sensing System : --------------------------- No-contact magnetic sensor
Range of tire circumference setting : ----- 10 mm - 2999 mm (Initial value 2096 mm)
Range of Operational Temperature : ------ 0
°
C - 40
°
C (32
°
F - 104
°
F)
Dimension and Weight(Computer) : ------ 38 x 54 x 17.5 mm [1-1/2 x 2-1/8 x 11/16'] / 28 g [1.0 oz]
* The factory-loaded battery life might be shorter than the above-mentioned specification.
* The specifications and design are subject to change without notice.
Limited Warranty
2
-Year Warranty : Computer Head Only (excluding the attached parts and deteriorated battery )
If any trouble or damage occurs during normal use, the product computer will be repaired or replaced
free of charge. Type your name, address, telephone number or e-mail address, date of purchase and
the situation of trouble and send it back together with the product to the closest address below. Trans-
portation charges shall be borne by the customer. After being repaired, the product will be shipped
back to the customer.
* Accessory parts are available for the customers as shown below.
Computer Operations
While Elapsed Time,
Trip Distance or Aver-
age Speed is displayed
Measurement
Unit Icon
Start or Stop of Measurements
The computer can be programmed to run in either MANUAL
MODE or AUTO TIME MODE. In Manual Mode you must press
the START / STOP button to turn on and off the Timer, which
records Distance and Average Speeds. In Auto Time the com-
puter turns the Timer on and off depending on a signal from the
sensor.
When speed is detected by the computer and the Timer is run-
ning, the km/h or mph will flash. Speed will appear on the com-
puter screen and the Odometer will record, regardless if the
Timer is running or not.
• Auto Time Mode (Automatic Measurement)
When the icon
is lit, the measurements are automatically
done. This is called auto-mode in which the rotation of the wheel
is detected to make the measurements start or stop automati-
cally. (When the icon
is lit, you cannot start or stop the mea-
surements by pushing the START/STOP button)
• Manual Measurements
When you don’t see the icon
on the screen, you can start or
stop the measurements by pushing the START/STOP button.
When you push the button, measurements Elapsed Time, Aver-
age Speed and Trip Distance are started, and stopped with the
second push of the button.
• How to set ON or OFF the Auto-Mode
Push the SET button while Elapsed Time (Tm) Trip Distance
(Dst) or Average Speed (Av) is displayed, then the icon
is
“lit” (ON) or turned OFF.
Resetting Elapsed Time, Trip Distance, Average and Max.
Speed
Push the MODE button and the START/STOP button at the same
time while the measurement other than Odometer, Elapsed
time, Maximum Speed, Average Speed and Trip Distance are
zeroed. The Odometer cannot be reset.
Close
Open
Computer Functions
• Power-Saving Function
When no signal has been received for about 1 hr, the computer switches to the
power-saving mode and only displays the Clock. When any button is pushed or the
bicycle is riden, the measurement mode comes back.
• Selection of The Data-display Mode
In Auto-Mode you can choose between Speed or Cadence to be displayed in the top
screen.
Speed is initially selected in the upper dis-
play. When the computer is in
mode,
press the START/STOP button. Cadence
will now appear in the upper display. Speed
will be in the lower display. Switch it back
with the same procedure.
Troubleshooting
No display appears.
Is the battery dead?
Replace it and do all clear procedure.
Strange data appears
Do all clear procedure.
Data of odometer is also erased.
Measurements do not start when the START/STOP button is pushed.
Is the icon
ON?
Make the Auto-Mode off to enable the start or stop of the measurements by manual opera-
tion of the button.
No speed data (cadence) can be measured.
(If the speed data (cadence) is not displayed, have the contact
points short-circuited a few times by a metal plate. In the case
that this short-circuiting is detected by the computer, the com-
puter is considered normal and the bracket and the sensor possi-
bly have the cause of trouble.)
Is the gap between the sensor and the magnet too big?
(should be within 5 mm)
Does the marked line of the sensor align with the center of
the magnet?
Adjust the position of the magnet and the sensor.
Make sure that the contact points of the bracket or of the main body are free from dirt.
Wipe the contact points clean.
Is the cord not broken? Even if the outside of the cord looks normal, a breakage in the wire can occur.
Replace the bracket and sensor set with a new one.
Maintenance
• To clean the computer or the attached parts, use diluted neutral
detergent on a soft cloth and wipe it off with a dry cloth.
Replacing The Battery
When the display becomes dim, replace the battery.
• Put a lithium battery CR2032 in the computer with the (+) mark
facing up.
• After replacing the battery, do the necessary set-up of the com-
puter in accordance with the “Computer Set-up”.
Standard Parts
Optional Parts
#169-9400
Bracket Sensor Kit
#169-9757
Attachment Kit
#169-9691
Wheel Magnet
#166-5150
Lithium Battery (CR2032)
#169-9765
Cadence Magnet
#169-9402
Center Mount Bracket Kit
#169-9403
Bracket Sensor Kit
for Aero Bar
#169-9404
Stem Mount
Bracket Kit
#169-9760
Magnet for Composit Wheel
Is the contact points located on
the backside short-circuited in-
termittently.
Cateye Astrale Cc Cd100 User Manual 2017
Speed
Cadence
Selection of the data-display mode (bottom of the screen)
Press the Mode button to navigate to each of the sub-displays listed on the right.
Press and hold the mode button for two seconds in any mode to display the Clock Time.
2-8-25, Kuwazu, Higashi Sumiyoshi-ku, Osaka 546-0041 Japan
Attn.: CAT EYE Customer Service Section
Service & Research Address for United States Consumers:
CAT EYE Service & Research Center
1705 14th St. 115 Boulder, CO 80302
Phone: 303-443-4595
Toll Free: 800-5CATEYE
Fax: 303-473-0006
e-mail: service@cateye.com
URL: http://www.cateye.com
