Introduction
Thank you for purchasing the AT-LP60-USB. Audio-Technica brings its
legendary quality and audio fidelity to the digital realm with this LP-to-
Digital Recording System. In the box, you’ll find everything you need
to transfer your classic LP collection to digital files: Audio-Technica’s
AT-LP60-USB stereo turntable, complete with USB output that allows
direct connection to your computer; Audacity recording software (for
MAC or PC); an integral dual-magnet Audio-Technica phono cartridge;
a USB cable and adapter cables. The turntable also offers a built-in
switchable phono/line preamp that allows connection to a stereo
system equipped with either a phono or line-level input.
AT-LP60-USB stereo turntable features:
• USB output –no special drivers required for direct connection
to your computer
• Built-in switchable stereo phono/line level pre-amplifier. Permits use
of turntable with stereo systems having either magnetic-phono inputs
or “AUX” (line-level) inputs; also allows convenient use of turntable
with most powered speakers
• PC & Mac compatible
• Fully automatic operation
• Two speeds: 33
1
/
3
RPM and 45 RPM
• Professional aluminum turntable platter
• Integral Audio-Technica Dual Magnet
™
phono cartridge with
replaceable diamond stylus
• Damped lift/cueing mechanism with front-panel control
• Removable dust cover
To assure maximum satisfaction from this product, please read the
information and follow the instructions presented in this manual. Please
keep the manual in an accessible location for future reference.
We suggest that you save all the packaging materials for possible future
storage, moving or shipping.
CAUTION: To avoid stylus damage, make certain the
included stylus guard is in place whenever the turntable
is being installed, moved or cleaned.
Stylus assembly
Stylus (“Needle”)
Stylus guard
Safety instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any of the ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding
plug. A polarized plug has two blades with one wider than the other.
A grounding plug has two blades and a third grounding prong. The
wide blade or the third prong is provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit
from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket or table specified by
the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has
been dropped.
15. Where a mains plug is used as the disconnect device, the
disconnect device shall remain readily operable.
16. Please keep the unit in a good ventilation environment.
17. Apparatus shall not be exposed to dripping or splashing and
no objects filled with liquids, such as vases, shall be placed
on apparatus.
Caution: To reduce the risk of fire or electric shock, do not expose
this apparatus to rain or moisture. The apparatus shall not be
exposed to dripping or splashing, and no objects filled with liquids,
such as vases, shall be placed on the apparatus.
Warning: To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture. The apparatus shall not
be exposed to dripping or splashing and that no objects filled with
liquids, such as vases, shall be placed on the apparatus.
Caution: To prevent electric shock, do not use this polarized plug
with an extension cord, receptacle or other outlet unless the blades
can be fully inserted to prevent blade exposure.
The lightning flash with arrowhead symbol within the
equilateral triangle is intended to alert the use to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock.
The exclamation point within the equilateral triangle is
intended to alert the user to the presence of important
operation and maintenance (servicing) instructions in
the literature accompanying this appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Initial Setup
Assembling the Turntable
The AT-LP60 requires some assembly before first use. IMPORTANT:
Do not connect the AC power cord until assembly is complete.
1. Carefully place the turntable platter on the center spindle,
making certain the platter is fully seated on the spindle.
2. While holding both ends of the red tape ribbon on the
turntable belt, carefully pull the belt over the motor pulley (Fig.
2a). (If the belt drops off, remove the turntable platter and put
the belt back on it, as described on page 7.)
3. Once the belt is seated in the pulley’s groove, carefully
remove the ribbon. Make certain the belt is not twisted.
4
Place the turntable mat on top of the turntable platter (Fig. 2b).
5. If desired, the hinged dust cover may be removed. Hold both
sides of the dust cover and pull upward gently and evenly to
detach the cover from the turntable (Fig. 2c). Keep the cover
in a safe, clean place.
6. To re-install the dust cover, guide the dust cover hinges into
the two hinge receptacles located at the back of the turntable
housing.
Setting the Pre-amp (Phono/Line) Switch
For increased flexibility of use, this turntable has an internal stereo
phono pre-amplifier. The Pre-amp Selector (Phono/Line) Switch is
located on the back of the turntable. If the stereo system you are using
has a PHONO input, set the Pre-amp Selector Switch to the “PHONO”
position. If your stereo system does not have a PHONO input, set
the Pre-amp Selector Switch to the “LINE” position and connect the
turntable’s output cables to the AUX or other high-level input on your
Audio Technica At-lp60 Manual
stereo system (described later) (Fig. 3).
PHONO
LINE
Audio-technica At-lp60 Manual
PHONO
“AUX”
Input
Jacks
Pre-amp
Selector
Switch
Speakers For Audio Technica Lp60
Stereo System
White
Red
AC
AC
Figure 3
2b – Record mat
2c – Dust cover removal
Audio-technica At-lp60usb
Figure 2 – Assembling the turntable
2a – Drive belt
Red ribbon
Motor spindle
Drive belt
Audio Technica Lp60 Manual
4
